SUN-30/33/35/40/50/60K-G04 | 30-60kW | Three Phase | 4 MPPT
Max. DC Input Power(kW) 45.5
Max. DC Input Voltage (V) 1000
Start-up DC Input Voltage(V) 250
MPPT Operating Range(V) 200~850
Max. DC Input Current(A) 40+40+40
Max. Short Circuit Current (A) 60+60+60
Number of MPPT/Strings per MPPT 3 / 3
Rated Output Power(kW) 40
Max. Active Power(kW) 44
Rated AC Grid Voltage(V) 230 / 400
AC Grid Voltage Range(V) 277Vac~460Vac(this may vary with grid standards)
Rated Grid Frequency(Hz) 50 / 60 (Optional)
Operating Phase Three phase
Rated AC Grid Output Current(A) 53/50.7
Max. AC Output Current(A) 58.3/55.8
Output Power Factor 0.8 leading to 0.8 lagging
Grid Current THD <3%
DC Injection Current(mA) <0.5%
Grid Frequency Range 47~52 or 57~62 (Optional)
Max.Efficiency 98.7%
Euro Efficiency 98 %
MPPT Efficiency >99%
Interface RS485/RS232/Wifi/LAN
Max. DC Input Voltage (V) 1000
Start-up DC Input Voltage(V) 250
MPPT Operating Range(V) 200~850
Max. DC Input Current(A) 40+40+40
Max. Short Circuit Current (A) 60+60+60
Number of MPPT/Strings per MPPT 3 / 3
Rated Output Power(kW) 40
Max. Active Power(kW) 44
Rated AC Grid Voltage(V) 230 / 400
AC Grid Voltage Range(V) 277Vac~460Vac(this may vary with grid standards)
Rated Grid Frequency(Hz) 50 / 60 (Optional)
Operating Phase Three phase
Rated AC Grid Output Current(A) 53/50.7
Max. AC Output Current(A) 58.3/55.8
Output Power Factor 0.8 leading to 0.8 lagging
Grid Current THD <3%
DC Injection Current(mA) <0.5%
Grid Frequency Range 47~52 or 57~62 (Optional)
Max.Efficiency 98.7%
Euro Efficiency 98 %
MPPT Efficiency >99%
Interface RS485/RS232/Wifi/LAN
